HFOV 123° M12 Wide Angle Lens

Focal Length 1.8mm M12 Wide Angle Lens

Description

The JSD2636 wide angle lens has the largest HFOV 121° on 1/2.5” sensor, distortion is only 5%.

Hybrid design with aspheric elements for superior resolution cameras, welcome to contact us for sample testing.

Application

l Sports & Action Camera

l Security & Security Camera

l 4K Video Conference Camera

l Drone

Specification

: 4.3mm Non Distortion M12 Lens

Description

The 4.3mm wide angle lens is a high resolution lens with non-distortion and metal construction. It’s designed for computer vision applications in the Aerial image, Robotics, Security and Machine Vision markets.

Application

l Aerial Image

l Robotics

l Security/Surveillance cameras

l Video Conference Camera

Specification

Model

JSD1329

Image sensor

1/2.3” CMOS

Image Circle

8.1mm

Resolution

12MP

Focal Length

4.3mm

Aperture

F/2.8

TTL

22mm

FOV

DFOV85° HFOV 71° VFOV 56°

Distortion

0.5%

: EFL 2.7mm M12 Lens for 1/2.3" 12MP sensor

Description

The 2.7mm wide-angle lens is designed for 12MP 1/2.3” cmos sensor, image circle 8.3mm enable it suitable for sensor up to 1/2.8” IMX415 sensor. HFOV 100 degrees on IMX317 sensor while distortion is only 1.5%.

Application

l Aerial Imaging

l Mobile Robotics

l Digital Still Camera

l Scanning

l Camcorder

l Video Conference Camera

Specification

Model

JSD2631

Image sensor

1/2.3”

Image Circle

8.3mm

Resolution

12MP

Focal Length

2.7mm

Aperture

F/2.8

TTL

22.5mm

FOV

DFOV 113° HFOV 100° VFOV 82°
