JSD1001
HFOV 52° on 1/2.7" sensor
No Distortion
All-glass structure
For ADAS application
Have M8 and M12 mount version
- Information
- Related Products
Description
The 5.7mm M8 lens has HFOV 52° on 1/3” sensor, all glass and aluminium exterior support temperature -20℃ to 80℃, no distortion for face recognition application
Specification
|
| |
Model | JSD1001 | |
Image sensor | 1/2.7” | |
Image Circle | 7mm | |
Resolution | 5MP | |
Focal Length | 5.7mm | |
Aperture | F2.8 | |
TTL | 10.29mm | |
FOV | DFOV 60° HFOV 52° VFOV 30° | |
Mount | M8 M12 | |
