JSD5042
S mount lens ultra wide angle lens large aperture
PN: JSD5042
F2.4
HFOV 99° 102°
TTL 27mm
Thread M16
Distortion <-10.20%
Image Sensor 2/3" 1/1.55"
- Information
- Related Products
The JSD5042 lens features a large F2.4 aperture, an ultra-wide horizontal field of view (HFOV 99°–102°), a compact overall length (TTL 27mm), and an M16 interface, making it a perfect choice for embedded vision applications that require a wide field of view, high light transmission, and minimal installation space.
Specification
Model | JSD5042 | |
Image sensor | 1/1.32” | |
Image Circle | 12.3mm | |
Resolution | 5MP | |
Focal Length | 4.36mm | |
Aperture | F2.4 | |
TTL | 29.89mm | |
FOV | DFOV 158° HFOV 129° VFOV 97° | |
Mount | M16 | |
