JSD3210

Description

The JSD3210 is a compact wide-angle fixed-focus lens with a focal length (EFL) of 3.2 mm, delivering a horizontal field of view (HFOV) ranging from 97° to 101°, which enables extensive scene coverage. It is compatible with both 1/2.7-inch and 1/2.8-inch image sensor formats, and its total track length (TTL) is maintained at 22.43 mm, reflecting a relatively compact structural design. The wide-angle design allows capturing broader scenes within limited distances, though such lenses typically exhibit a certain degree of barrel distortion, which can be corrected through software algorithms

Application

Security & Surveillance: Used for indoor and outdoor monitoring cameras requiring panoramic coverage.

Smart Home Devices: e.g., wide-angle smart doorbells, household surveillance cameras.

Automotive Imaging Systems: Served as dash cams or blind spot monitoring cameras.

Industrial Vision Inspection: Used for machine vision positioning or preliminary inspection requiring a wide field of view.

Consumer Electronics: Integrated into Internet of Things (IoT) devices with visual function requirements.

Specification
