Drones are the new industrial inspectors. They scan bridges, monitor pipelines, and map construction sites. The drone platform is smart. The flight controller is advanced. But the data is only as good as the lens. Bad glass means bad data.

Enter the JSD3840.

This is not for taking vacation photos from the sky. This is an industrial optical core built for precision, mapping, and critical analysis.

1. The Death of the Fish-Eye

Wide angles cover more ground. Usually, they warp the world. Power lines curve. Horizons bend. This destroys photogrammetry models. Software struggles to stitch warped images.

The JSD3840 solves this. It offers a broad 100° Field of View (FOV). It sees a massive area. The game-changer is the Distortion <0.4%. The image is geometrically correct. Straight lines remain straight. Mapping software processes the data instantly. Accuracy increases. Post-processing time drops.

2. Every Pixel Counts

Finding a hairline crack in concrete requires resolution. Spotting rust on a bolt demands clarity.

This lens resolves a stunning 20 Megapixels. It is designed for a large 1/1.8" Image Circle. The EFL 3.76mm focal length provides the perfect balance of width and detail. Light hits the sensor perfectly. The edges are sharp. The center is crisp. The drone flies high; the details remain grounded in reality.

3. Fly Lighter, Fly Longer

Every gram on a drone reduces battery life. Heavy lenses kill flight time.

The JSD3840 utilizes a compact M12 Thread. The Total Track Length (TTL) is a tiny 15.8mm. It fits into lightweight gimbals effortlessly. It sits close to the sensor. The payload is lighter. The drone covers more acres per charge. Efficiency goes up.

4. Consistent Data

Light conditions change. Clouds move. Shadows shift. The F/NO 4.0 aperture handles it all. It provides a deep depth of field. Focus is consistent. From the top of a wind turbine to the ground below, clarity is uniform.

Specs for the Mission:

Model: JSD3840

Precision: <0.4% Distortion

Vision: 100° FOV

Detail: 20MP Resolution

Format: 1/1.8"

Size: 15.8mm TTL

Industrial inspection is about truth. It is about data. Equip the fleet with the JSD3840. Capture the world exactly as it is.
