JSD1120

Product Overview

This ultra-compact M7 mount fixed focal lens (PN: JSD1120) is expertly engineered for miniature 1/5-inch sensors, delivering expansive coverage and reliable clarity for space-constrained imaging applications. With an extremely short 1.1mm focal length and a bright F2.0 aperture, it provides a massive 164° field of view, making it ideal for immersive visual systems, medical devices, and compact monitoring tools. Featuring 2MP resolution and a tiny form factor, this lens ensures superior scene capture capabilities where standard lenses cannot fit.

Key Features & Benefits

2MP HD Resolution:Designed to support 2 Megapixel sensors, offering sharp image definition and detail suitable for miniature cameras and endoscopic applications.

Ultra-Wide 164° FOV:Provides a massive 164-degree field of view, allowing for panoramic scene capture and immersive imaging with a single lens.

Miniature M7 Mount:Features a specialized, small-format M7 thread with a Total Track Length (TTL) of just 10mm, specifically designed for ultra-compact devices and embedded systems.

Perfect Sensor Match:Engineered specifically for 1/5" sensors, ensuring the 164° view is fully projected onto the sensor with a compatible image circle.

Bright F2.0 Aperture:The wide aperture allows for excellent light intake, ensuring clear performance even in challenging or low-light environments.

Controlled Optical Design:With distortion controlled at <-17.58%, the lens balances an extreme wide-angle perspective with image usability, typical for fisheye-style micro lenses.

Wide Application Versatility:Perfectly suited for miniature electronics, medical imaging, and industrial inspection tasks requiring maximum coverage in minimum space.

Applications

Medical Endoscopes & Boroscopes

Miniature Surveillance Cameras

Wearable Body Cameras

Drone FPV (First Person View) Systems

IoT Sensors & Smart Home Devices

Industrial Inspection (Pipe/Tube cameras)

Automotive Interior Monitoring

Specification

Why Choose JSD Optoelectronics?

Shenzhen JSD Optoelectronics is a leading manufacturer of custom optical lenses, specializing in high-precision solutions since 2009. We offer:

1).ISO 9001 & IATF 16949 Certified Quality

2).Rapid Prototyping (15-day custom sample turnaround)

3).End-to-End Support from design to mass production

4).300+ Standard Designs for immediate sampling

drawing
