JSD2922

Product Overview

This compact M8 mount fixed focal lens (Model: JSD2922) is expertly engineered for 1/2.8-inch sensors, delivering high-definition clarity and expansive coverage for compact imaging devices. With a 2.9mm focal length and a bright F2.0 aperture, it provides an impressive ultra-wide 152° field of view, making it ideal for automotive, security, and IoT applications where broad scene capture is essential. Featuring 5MP resolution and a robust optical design with controlled distortion (<-22%), this lens ensures superior image sharpness and reliability in a space-saving form factor.

Key Features & Benefits

5MP High Definition:Delivers crisp, high-resolution imaging that maximizes the potential of 5MP sensors, ensuring detailed video capture for security and inspection needs.

Ultra-Wide 152° FOV:Provides a massive field of view, significantly wider than standard lenses, ideal for panoramic surveillance, dash cams, and environmental monitoring with minimal blind spots.

Perfect Sensor Match:Designed specifically for 1/2.8" sensors to produce a focused image circle that fully utilizes the sensor's active area without vignetting.

Bright F2.0 Aperture:Allows for excellent light intake, ensuring clear and bright images even in low-light environments or challenging lighting conditions.

Compact M8 Design:Featuring a standard M8 thread and a Total Track Length (TTL) of just 14mm, this lens is optimized for small-footprint devices and embedded systems where space is at a premium.

Optimized Optical Performance:With distortion controlled to <-22%, the lens balances an ultra-wide viewing angle with image naturalness, suitable for specific wide-angle algorithms.

Applications

Automotive Cameras (Dash Cams, Rear View)

Video Doorbells & Smart Home Devices

Sports & Action Cameras

Wide-Area Security Surveillance

IoT & Embedded Vision Systems

Drone & Aerial Imaging (FPV)

VR/AR Imaging Devices

Specification

Why Choose JSD Optoelectronics?

Shenzhen JSD Optoelectronics is a leading manufacturer of custom optical lenses, specializing in high-precision solutions since 2009. We offer:

1).ISO 9001 & IATF 16949 Certified Quality

2).Rapid Prototyping (15-day custom sample turnaround)

3).End-to-End Support from design to mass production

4).300+ Standard Designs for immediate sampling

drawing
