JSD9070

Product Overview

This high-precision M12 mount fixed focal lens (Model: JSD9070) is expertly engineered for 1/2.8-inch sensors, delivering uncompromising geometric accuracy for specialized imaging applications. With a 9.04mm focal length and an F7.0 aperture, it provides a focused 40° field of view with an extended depth of field. Distinguished by its ultra-low distortion (< -0.38%), this lens is virtually distortion-free, making it the perfect solution for Optical Character Recognition (OCR), document scanning, and industrial measurement tasks where straight lines and dimensional precision are paramount. Featuring 8MP resolution, it ensures exceptional sharpness across the entire image circle.

Key Features & Benefits

True 8MP Resolution:Delivers sharp, high-definition imaging with excellent detail retention, essential for reading fine text or capturing minute details in inspection tasks.

Ultra-Low Distortion (< -0.38%):Features superior optical correction that virtually eliminates barrel distortion. This "Zero Distortion" performance ensures that straight lines remain perfectly straight, which is critical for measurement and scanning applications.

Extended Depth of Field:The F7.0 aperture design provides a deep depth of field, ensuring that objects at varying distances remain in focus simultaneously, ideal for scanners and document capture.

Targeted 40° FOV:The 9.04mm focal length offers a standard 40° field of view, providing a closer, more detailed look at the subject compared to wide-angle lenses, suitable for focusing on specific targets.

Perfect Sensor Match:Engineered specifically for 1/2.8" sensors, ensuring full coverage of the image sensor with uniform edge-to-edge clarity.

Compact & Low Profile:With a Total Track Length (TTL) of just 12.35mm, this lens is exceptionally compact, allowing for integration into slim handheld devices, scanners, and industrial probes.

Applications

Optical Character Recognition (OCR)

Document & Passport Scanning

Barcode & QR Code Reading

Industrial Metrology & Measurement

Machine Vision Inspection

Biometric Identification

Medical Imaging Devices

Specification

Why Choose JSD Optoelectronics?

Shenzhen JSD Optoelectronics is a leading manufacturer of custom optical lenses, specializing in high-precision solutions since 2009. We offer:

1).ISO 9001 & IATF 16949 Certified Quality

2).Rapid Prototyping (15-day custom sample turnaround)

3).End-to-End Support from design to mass production

4).300+ Standard Designs for immediate sampling
