5MP Lens JSD2026 2.7mm 149° DFOV F2.0 Large Aperture 1/2.8" M12 Mount Lens for Sony IMX662

Product Overview
This ultra-wide-angle M12 mount fixed focal lens is high-performance optics engineered for 1/2.8-inch image sensors, delivering an expansive perspective for comprehensive situational awareness. Featuring a short 2.7mm focal length and a bright F2.0 aperture, it provides a panoramic 149° field of view, making it an ideal choice for immersive surveillance and wide-area monitoring where maximum coverage is the primary objective. With a compact 23.00mm Total Track Length (TTL) and a streamlined Φ6.8mm diameter, this lens offers a powerful wide-angle solution for space-constrained vision systems requiring high light throughput.

Sensor

Compatible with the following sensors, this lens can also be deeply customized to align perfectly with your unique requirements.

Sony IMX335

Sony IMX415

Sony IMX307 / IMX327

SmartSens SC530AI / SC5235

OmniVision OS05A10

Key Features & Benefits

• Panoramic 149° Field of View: Delivers an ultra-wide perspective that captures vast environments in a single frame, significantly reducing the number of cameras needed for full area coverage.

• Enhanced Low-Light Performance (F2.0): The large F2.0 aperture allows for superior light intake, ensuring clear, high-contrast imaging even in challenging or low-illumination environments.

• Optimized for 1/2.8" Sensors: Precision-tailored for the popular 1/2.8" sensor format, maximizing optical efficiency and ensuring consistent resolution across the wide-angle field.

• Ultra-Compact Micro Profile: With a specialized Φ6.8mm diameter and a 23.00mm TTL, this lens features one of the smallest footprints in its class, perfect for discrete installations and miniature devices.

• Industrial-Grade M12 Mount: Utilizes the standard M12*P0.5 thread, providing a secure and versatile interface for easy integration into professional AIoT, security, and automotive modules.

• Dynamic Visual Depth: The 2.7mm optical design provides an expansive depth of field, ensuring that objects both near and far remain in functional focus for real-time monitoring.

Applications

• Wide-Angle Security & Panoramic Surveillance (Indoor/Outdoor)

• Automotive Dashcams & Backup Cameras

• Smart Home Doorbell & Intercom Systems

• UAVs & Drone Navigation Vision

• Robotic Vacuum & SLAM Navigation

• Action Cameras & Wearable Video Devices

• Wide-Field Industrial Monitoring

Specification

Why Choose JSD Optoelectronics?

Shenzhen JSD Optoelectronics is a leading manufacturer of custom optical lenses, specializing in high-precision solutions since 2009. We offer:

1).ISO 9001 & IATF 16949 Certified Quality

2).Rapid Prototyping (15-day custom sample turnaround)

3).End-to-End Support from design to mass production

4).300+ Standard Designs for immediate sampling

If you would like to customize a lens, please send an email to: info@jsdoptical.com
