JSD0221

Product Overview

This compact M7 mount fixed focal lens is expertly engineered for 1/4-inch sensors, delivering reliable clarity and geometric accuracy for compact imaging applications. With a 4.19mm focal length and F2.6 aperture, it provides a natural 70° field of view, making it ideal for biometric recognition, video communication, and targeted monitoring. Featuring 1MP resolution and a controlled distortion design, this lens ensures balanced image quality and precise subject representation within a lightweight, space-saving form factor.

Key Features & Benefits

Reliable 1MP Resolution:Delivers clear imaging with sufficient detail for recognition tasks, video conferencing, and standard machine vision analysis.

Natural 70° FOV:Provides a focused field of view (70° Diagonal) that offers a natural perspective without extreme wide-angle deformation, perfect for face scanning and object detection.

Perfect Sensor Match:Optimized specifically for 1/4" image sensors, ensuring full image circle coverage and maximizing sensor performance in small-scale devices.

Low Distortion Design:Advanced optical engineering maintains distortion below -6.77%, ensuring straight-line accuracy and true-to-life image representation for scanning and inspection needs.

Compact M7 Architecture:Featuring a standard M7 thread and a Total Track Length (TTL) of just 11.87mm, this lens is designed for seamless integration into portable, handheld, and space-constrained IoT hardware.

Balanced Optical Performance:The F2.6 aperture offers a practical balance between depth of field and light sensitivity, suitable for diverse indoor lighting conditions.

Applications

Biometric Recognition (Face/Iris)

Video Conferencing & Webcams

Handheld Scanners & Barcode Readers

IoT Smart Home Devices

Indoor Security Monitoring

Embedded Vision Systems

Specification

Why Choose JSD Optoelectronics?

Shenzhen JSD Optoelectronics is a leading manufacturer of custom optical lenses, specializing in high-precision solutions since 2009. We offer:

1).ISO 9001 & IATF 16949 Certified Quality

2).Rapid Prototyping (15-day custom sample turnaround)

3).End-to-End Support from design to mass production

4).300+ Standard Designs for immediate sampling

drawing
