JSD2012

Product Overview

This lens is available in M7, M8, and M12 thread versions. This ultra-miniature M7 mount fixed focal lens (PN: JSD2012) is expertly engineered for compact 1/4-inch sensors, delivering reliable imaging performance in a microscopic form factor. With a 2.09mm focal length and F2.6 aperture, it provides a wide 135° field of view, making it ideal for medical imaging, wearable technology, and compact surveillance where space is severely restricted. Featuring 2MP resolution and a highly compact TTL of 11.9mm, this lens ensures clear scene capture and versatile integration into the smallest embedded vision devices.

Key Features & Benefits

Reliable 2MP Resolution: Delivers clear High-Definition (HD) imaging, ensuring sufficient detail for inspection, monitoring, and video streaming applications on compact 1/4" sensors.

Wide 135° FOV:Provides an expansive 135° field of view, allowing for broad situational awareness and panoramic scene capture, significantly reducing blind spots in close-range applications.

Optimized for 1/4" Sensors:Engineered specifically to match the optical requirements of 1/4" sensors, ensuring the image circle fits perfectly to utilize the sensor's full potential without vignetting.

Immersive Wide Perspective:With a distortion profile of <-54%, this lens utilizes a fisheye-style projection to capture a vast area, making it ideal for environmental monitoring and immersive viewing experiences where coverage is priority.

Miniature M7 Mount Design:Featuring a standard M7 thread and a compact TTL of 11.9mm, this lens is designed for lightweight, portable, and wearable devices where every millimeter of space counts.

Precise Focal Adjustment:The threaded M7 mount allows for fine tuning of the back focal length during assembly, ensuring optimal sharpness for specific object distances.

Cost-Effective Performance:Offers a robust optical solution for budget-conscious projects requiring wide-angle coverage in a tiny package.

Applications

Medical Endoscopes & Borescopes

Wearable Cameras (Body Cams, Smart Glasses)

Miniature IoT & Smart Home Devices

Pipe & Industrial Inspection

Compact Biometric Scanners

Miniature Drones (FPV)

Hidden/Covert Surveillance Systems

Specification

Why Choose JSD Optoelectronics?

Shenzhen JSD Optoelectronics is a leading manufacturer of custom optical lenses, specializing in high-precision solutions since 2009. We offer:

1).ISO 9001 & IATF 16949 Certified Quality

2).Rapid Prototyping (15-day custom sample turnaround)

3).End-to-End Support from design to mass production

4).300+ Standard Designs for immediate sampling

drawing
